73
7−18. Check mode
The following confirmations can be made in the Check mode.
・Check of ROM version
・Check of the mounting option
・Check of bridge voltage
・Check of the external control input
・Check of the contact output
・Check of the analog output
・Check of the BCD output (option)
● The check on the BCD output will be operated only when the BCD
output is installed.
● The instrument can return to the Measurement mode by pressing the
key even in the halfway of the Check mode.
7−18−1. Operating procedure for the check mode
● When the key is pressed with the load display of “FUNC”, the
display will change as the following arrow marks indicate at every
time the key is pressed. However, every time the key is pressed,
the display will change as the reverse direction of the following arrow
marks.
“FUNC”→“CCAL”→“ACAL”→“LCAL”→“ZERO”→“SPAN”
→“TARE”→“CHEK”→“MONT”→“VCAL”→“VADJ”→“FUNC”
→“CCAL”・・・・・（Hereinafter over and over again.）
