9−5. Serial interface
Warning ● When the CHECK switch is applied, pay attention to the following
points.
1
By ON operation of CHECK, the instrument isn’t in Measurement
mode anymore(RUN display puts off, RUN output is open.),
however, Serial interface keeps on outputting.
2
By ON operation of CHECK, “OL” error display might be seen.
At the same time serial interface will output after setting the ERR
bit for output format.
9−5−1. Related function
FUNC−88
Selection of output
types
Stream, Stream+Automatic printing,
Stream+Manual printing
9−5−2. Specifications for Interface
(1) Method 2 wires method serial interface.
(2) Specification for signal
Baud rate 600 bps
Data bit length 8 bits
Parity bit ODD
Stop bit 1 bit
Start bit 1 bit
