7−10. Change of bridge power supply voltage
The instrument can select the bridge power supply from “5 V” and “2.5 V”. This selection can be
made in the Function mode(Related function F−12). Default has selected “5 V”.
● When the bridge power supply voltage is changed, please execute the
calibration again.
7−11. Tare weight cancellation (A/Z)
The instrument prepares Tare weight cancellation (A/Z) function.
Pressing the
key makes Tare weight cancellation (A/Z) function operated and when the load
display becomes net weight display, at the same time, the “A/Z” lights up on the status display and
load display value becomes “0”.
Moreover, when the
key is pressed, Tare weight cancellation clear(A/Z OFF) function will
activate and at the same time when the load display value becomes gross weight, the “A/Z” on the
status display will put off.
● When tare weight cancellation (A/Z) function is required, select
“00001：A/Z function effective” by function F−70.
Upon this selection, “◎” on the status display will be light on, and
A/Z function will be active.
7−12. Zero set
The instrument prepares zero set function.
When the display value on load display is within 10 % against the maximum display value (Refer to
the chapter 5.), by press of the
key together with the press of key, the zero set function
works and the display is made “0” compulsorily.
However, zero set will not be accepted when zero compensation for total ±10 % is executed with
zero set and zero tracking until that time. (ERR−0 display)
Also, the same operation can be made with the operation of “ZERO” at the input signal of external
control. Cancellation for data applied zero compensation by zero set can be executed with Function
F−98.
● When tare weight cancellation (A/Z) is executed (during A/Z display
lights up), zero set will not be accepted. It will display “ER−5”.
When zero set is desired to execute, execute after making the Tare
weight cancellation clear (A/Z OFF).
