6. Operation procedure
We’ll show the operating procedures with keys located on the front panel.
Warning ● Each key operation should be made after interrupting the
measurement. If it is made during measurement, it may cause an
unexpected malfunction.
● Key operation in Measurement mode can be effective by pressing it for
about one second or so.
6−1. key
6−1−1. Operations in Measurement mode
(1) When it is operated alone.
The Function mode can be entered, and the “FUNC” is shown on the load display section.
In this condition, setting on the Function or shifting to another modes can be available.
(2) When it is operated while the press of key.
If you will operate while the press of
key, the CHECK value set in function F−11 is turned
on, and “CHECK” in the condition display section lights. At the same time, the load value
which corresponds to the value set in the load indicated value with F−11 is added.
After operating while the press of
key, the CHECK value is turned off, and returns to the
former status.
6−2. key
6−2−1. When operating in the measurement mode
The set value of comparator S1 is displayed at the same time as S1 LED blinking, 10
0
digits
blink, and setting the set value of comparator S1 becomes possible.
Moreover, the display automatically returns to the measurement mode when leaving without
operating key of anything under such a condition for about 20 seconds.
The changed set value is registered internally when do the press of
key, and the operation
comes off the status where the S1 set value can be set.
