7−8. Various functions concerning display
7−8−1. Selection of target of display
The instrument can select the display frequency from 4 times/s and 20 times/s. This selection is
done in the function mode (related function F−03). Default has selected 4 times/s.
● The comparator of the instrument executes comparative operation
synchronous with the display. Besides, the conversion of analog
output is synchronous with the display.
In due course, when changing of conversion times of comparator, and
also conversion times of analog output is/are required, execute the
change of display times with the function F−03.
7−8−2. Selection of position of decimal point display
The instrument can display the decimal point at the “Load display section” of the instrument.
The selection of display can be made in the Function mode. (Related function F−01) Default has
selected “No decimal point display”.
7−8−3. Load display range
The load display range for the instrument is fixed from the −10 % to 110 % of the maximum
display value at the time of setting during calibration. When less than the range, “−OL”
displays and over the range “OL” displays. For example, when the maximum display value is
“1 000”, the load display range will be from −100 to 1 100.
Besides, when under −100, the “−OL” displays, and over 1 100, the “OL” will display.
7−9. Selection the target for HOLD
The instrument can select the target for HOLD function among “load display”, “comparator
contact output of S1 and S2, LED display”, “Analog output” and “Options”.
This selection can be made in the Function mode(Related function F−10).
As for the default, “All is selected.” Layout of setting for the F−10 are as follows：
10
0
digit：Load display
10
1
digit：Contact output of comparator S1 and S2, LED display
10
2
digit：Analog output
10
3
digit：Optional output
※With the “0” setting, out of the target, and with “1” setting, target of HOLD.
● When HOLD target ”Load display” is selected, key, key and
key becomes invalid.
