VII
History of revision
Date Instruction Manual No. Details of revised point
Dec. 2000
DRW.NO.EN294−1127 First Version ROM Ver. 1.000 or later
Mar. 2001
DRW.NO.EN294−1127−A
ECN No.FN01−02042
− Correction −
P.49 7−1−1. Input signal for external control
“During the holding operation, it is reset condition by short
circuit.”→“During the peak hold operation, reset condition
is made by short circuit.”
P.91 9−2−6 Output condition at Positive logic
Output data “Yes”→Condition of transistor “OFF”
Output data “No”→Condition of transistor “ON”
Mar. 2001
DRW.NO.EN294−1127−B
ECN No.FN01−02041 ROM Ver.1.300 or later
− Correction −
5−2−1. 6th step.
Add the clause “
It can be increased 〜”
5−2−3. 12th step.
Change the display of “SP−L” and “SP−H”
11−1. Specifications for analog Input filter
“2 Hz”→ “1 Hz(At the “0” setting of the digital filter and
stabilized filter)”
− Change −
7−13. “Key lock”→ “Lock of key function”,
According to this change, following sentence is corrected.
8−2. F−06 “Setting key lock”
→ “Setting the lock of key function”
According to this change, following setence is also
corrected.
Jun. 2001
DRW.NO.EN294−1127−C
ECN No.FN01−02085
− Correction ‐
Change the outline dimensions (upper part)
− Additions ‐
9−6−2., 9−7−2, 11−11−6. add the “Power consumption”.
Jul. 2001
DRW.NO.EN294−1127−D
−Correction−
9−2−4.
(1)Equivalent circuit of input section “COM.1”→ “COM.”
(2)Equivalent circuit of output section “▼”→ “▽”
Sep. 2001
DRW.NO.EN294−1127−E
Due to ECN No.FN01−02134
−Changeー
Operating temperature range
“0 ℃ to 50 ℃”→ “−10 ℃ to 50 ℃”
May. 2003
DRW.NO.EN294−1127−F
Due to ECN No.FN03−02040
−Correction−
4−3−5.(2) “4mA to 20mA” to “DC4mA to 20mA”
7−2−4., (1), 7−15−4., 6−2., 9−1−1., 9−2−1., 9−2−2.
9−3−1., 11−7., “Display interlock”→“PEAK/Net weight”
Aug. 2003
DRW.NO.EN294−1127−G
Due to ECN No.FN03−02118
− Correction −
11−2. Specifications for digital section
Display range “−99 999”→ “9 999”
