(2) Command mode
1
Reading out the load data(Host→701B)
Command No.
Operation
21 Reading out TRACK/Gross
weight
22 Reading out the display data
Return(CSD−701B→Host)
2 4 6 8 10 12 14
@ 0 0 2 2 Terminator
Load data
Sign of load data
Command No.
D The load data enters from the right end.
D When the data is minus, “−” sign and when plus, “＋” sign is added.
D Load weighing data performs zero suppress.
D In case that the decimal point is set with the F−56, and at the same time the
decimal point is specified with the F−01, it will be added to the specified
position.
D The message will be output at the time of overloaded.
D The empty sections are all spaces.
2 4 6 8 10 12 14
@ 0 0 2 2 − 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 ＋ 0 . 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 ＋ O L Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 − O L Terminator
246
@ 0 0 2 2 Terminator
