Minebea CSD-701B - Page 53

40
Procedures
3
Press the  key.
The “TARE” mode can be entered.
The display on the load display section will show
“ZERO”.
Press the  key.
The display of “ZERO” on the load display
section will flash on and off, and Tare weight
cancellation will be entered.
 Warning ： At the same time, care should
be taken not to apply load variation due to
vibration and so on.
If load variation is applied, zero point
becomes unstable, so there is a possibility
that correct zero can’t be read.
4
When completed, the indication of load
display will show “END”.
However, when the initial load isn’t entered
within the range of −0.3 mV/V and 2.4 mV/V,
the error code in the right will be shown for
about 2 seconds, then the display on the load
display will show “TARE”, and returns to the
step 2.
TE−L：Zero point −OVER
TE−H：Zero point ＋OVER
Error code
Error code
Press the  key.
After quitting from the “TARE” mode, the load
di l
ill
h
th
t
ld
l
5
display will sho
w
th
e
present load value.
