2. Product presentation
MiR600 User Guide (en) 08/2021 - v.1.0 ©Copyright 2021: Mobile Industrial Robots A/S. 24
Pos. Description Pos. Description
Manual brake release switch on
page27
5 Dynamic brake contactors: used
by the safety system to stop the
robot when a safety function is
triggered
Side compartments
The side compartments contain the bogies and drive wheels.
To access a side compartment, see Accessing the internal parts on page39.
NOTICE
The unique nameplate of your robot is to be mounted on the right side
compartment hatch—see Mounting the nameplate on page64. Make sure
you do not swap the hatch with hatches from other robots.
Side compartment components
The left and right side compartment components are listed in Table 2.5.
