Mitsubishi F700 Series User Manual

116
Motor brake and stop operation
REMARKS
 When Pr. 522  "9999", output stop function disables DC injection brake operation, so the motor coasts to a stop when the output
frequency falls to Pr. 522 or lower. Re-acceleration during coasting may cause an inverter trip depending on the parameter
setting.
 Output stop function is disabled during PID control, JOG operation, power failure stop, and traverse function.
 Output stop function does not operate during reverse rotation deceleration. However, when the frequency setting signal and
output frequency falls to Pr. 522 or lower, the inverter coasts to a stop.
 During the output stop due to the output stop function (when forward/reverse command is given, but frequency command is not
given), FWD/REV LED indication on the operation panel flickers fast.
Parameters referred to 
Pr. 10 DC injection brake operation frequency , Pr. 11 DC injection brake operation time , Pr. 12 DC injection brake operation voltage Refer to page 106
Pr. 13 Starting frequency Refer to page 97

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
