Frequency setting by analog input (terminal 1, 2, 4)
4
PARAMETERS
(b) Method to adjust any point without application of a voltage (current) to across terminals 2 and 5 (4 and 5).
(To change from 4V (80%) to 5V (100%))
REMARKS
By pressing after step 10, you can confirm the current frequency setting bias/gain setting.
It cannot be confirmed after execution of step 11.
Press twice to show the next parameter ( ).
By turning , you can read another parameter.
Press to return to the indication (step 8).
Flicker...Parameter setting complete!!
(Adjustment completed)
Flicker...Parameter setting complete!!
C0 to C7 setting
is enabled.
Analog voltage (current)
value (%) across terminals 2-5
(across terminals 4-5)
5.
Turn to change it to the setting value
of " ".
4. Press to read the present set value.
" " (initial value) appears.
6. Press to set.
7.
Turn until appears.
8. Press to display .
9.
Turn until ( )
appears. Set to C4 Terminal 2 frequency
setting gain.
10. Press to display the analog voltage
(current) value (%).
The parameter
number read
previously appears.
1. Confirm the RUN indication and operation
mode indication
The inverter must be at a stop.
The inverter must be in the PU operation
mode.(Using )
2. Press to choose the parameter
setting mode.
Display
Operation
The gain frequency is
reached when the analog
voltage (current) value across
terminals 2-5 (across terminals
4-5) is 100%.
11.
Turn to set the gain voltage (%).
"0V (0mA) equals to 0%, 5V (10V, 20mA) to
100%"
REMARKS
The current setting at the instant of
turning is displayed.
3.
until appears.
Turn
Terminal 2 input Terminal 4 input
12. Press to set.
Terminal 2 input
Terminal 4 input

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
