Mitsubishi F700 Series User Manual

385
44
Second acceleration/deceleration time
2C AC 0
  
45
Second deceleration time
2D AD 0
 
46
Second torque boost
2E AE 0
  
47
Second V/F (base frequency)
2F AF 0
 
48
Second stall prevention operation current
30 B0 0
  
49
Second stall prevention operation
frequency
31 B1 0
 
50
Second output frequency detection
32 B2 0
  
51
Second electronic thermal O/L relay
33 B3 0
 
52
DU/PU main display data selection
34 B4 0
  
54
CA terminal function selection
36 B6 0
 
55
Frequency monitoring reference
37 B7 0
  
56
Current monitoring reference
38 B8 0
 
57
Restart coasting time
39 B9 0
  
58
Restart cushion time
3A BA 0
 
59
Remote function selection
3B BB 0
  
60
Energy saving control selection
3C BC 0
 
65
Retry selection
41 C1 0
  
66
Stall prevention operation reduction
starting frequency
42 C2 0
 
67
Number of retries at fault occurrence
43 C3 0
  
68
Retry waiting time
44 C4 0
 
69
Retry count display erase
45 C5 0
  
70
Special regenerative brake duty
46 C6 0
 
71
Applied motor
47 C7 0
  
72
PWM frequency selection
48 C8 0
 
73
Analog input selection
49 C9 0
  
74
Input filter time constant
4A CA 0
 
75
Reset selection/disconnected PU
detection/PU stop selection
4B CB 0

 
76
Fault code output selection
4C CC 0
 
77 *
Parameter write selection
4D CD 0
  
78
Reverse rotation prevention selection
4E CE 0
 
79 *
Operation mode selection
4F CF 0
  
80
Motor capacity
50 D0 0
 
90
Motor constant (R1)
5A DA 0



100
V/F1(first frequency)
00 80 1
 
101
V/F1(first frequency voltage)
01 81 1
  
102
V/F2(second frequency)
02 82 1
 
103
V/F2(second frequency voltage)
03 83 1
  
104
V/F3(third frequency)
04 84 1
 
105
V/F3(third frequency voltage)
05 85 1
  
106
V/F4(fourth frequency)
06 86 1
 
107
V/F4(fourth frequency voltage)
07 87 1
  
108
V/F5(fifth frequency)
08 88 1
 
109
V/F5(fifth frequency voltage)
09 89 1
  
117
PU communication station number
11 91 1
*3 *3
118
PU communication speed
12 92 1
 *3 *3
119
PU communication stop bit length
13 93 1
*3 *3
120
PU communication parity check
14 94 1
 *3 *3
121
Number of PU communication retries
15 95 1
*3 *3
122
PU communication check time interval
16 96 1
 *3 *3
* Read and write from communication with PU connector only is enabled.
Parameter Name
Instruction Code *1
Parameter
Copy
*2
Parameter
Clear
*2
All Parameter
Clear
*2
Read Write Extended

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
