Mitsubishi F700 Series User Manual

389
338
Communication operation command
source
26 A6 3
*3 *3
339
Communication speed command source
27 A7 3
 *3 *3
340
Communication startup mode selection
28 A8 3
*3 *3
341
RS-485 communication CR/LF selection
29 A9 3
 *3 *3
342
Communication EEPROM write selection
2A AA 3
 
343
Communication error count
2B AB 3
  
345
DeviceNet address
2D AD 3
*3 *3
346
DeviceNet baud rate
2E AE 3
 *3 *3
349
Communication reset
selection
31 B1 3
*3 *3
387
Initial communication delay time
57 D7 3
  
388
Send time interval at heart beat
58 D8 3
 
389
Minimum sending time at heart beat
59 D9 3
  
390
% setting reference frequency
5A DA 3
 
391
Receive time interval at heart beat
5B DB 3
  
392
Event driven detection width
5C DC 3
 
414
PLC function operation selection
0E 8E 4

 
415
Inverter operation lock mode setting
0F 8F 4
 
495
Remote output selection
5F DF 4
  
496
Remote output data 1
60 E0 4
 
497
Remote output data 2
61 E1 4
  
498
PLC function flash memory clear
62 E2 4
 
500
Communication error execution waiting
time
00 80 5
 *3 *3
501
Communication error occurrence count
display
01 81 5


502
Stop mode selection at communication
error
02 82 5
 *3 *3
503
Maintenance timer
03 83 5
 
504
Maintenance timer alarm output set time
04 84 5



505
Speed setting reference
05 85 5
 
506
Parameter 1 for user
06 86 5
  
507
Parameter 2 for user
07 87 5
 
508
Parameter 3 for user
08 88 5
  
509
Parameter 4 for user
09 89 5
 
510
Parameter 5 for user
0A 8A 5
  
511
Parameter 6 for user
0B 8B 5
 
512
Parameter 7 for user
0C 8C 5
  
513
Parameter 8 for user
0D 8D 5
 
514
Parameter 9 for user
0E 8E 5
  
515
Parameter 10 for user
0F 8F 5
 
522
Output stop frequency
16 96 5
  
539
Modbus-RTU communication check time
interval
27 A7 5
*3 *3
542
Communication station number (CC-
Link)
2A AA 5
 *3 *3
543
Baud rate selection (CC-Link)
2B AB 5
*3 *3
544
CC-Link extended setting
2C AC 5
 *3 *3
549
Protocol selection
31 B1 5
*3 *3
550
NET mode operation command source
selection
32 B2 5
 *3 *3
551
PU mode operation command source
selection
33 B3 5
*3 *3
553
PID deviation limit
35 B5 5
  
554
PID signal operation selection
36 B6 5
 
Parameter Name
Instruction Code *1
Parameter
Copy
*2
Parameter
Clear
*2
All Parameter
Clear
*2
Read Write Extended

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
