390
555
Current average time
37 B7 5
  
556
Data output mask time
38 B8 5
 
557
Current average value monitor signal
output reference current
39 B9 5
  
561
PTC thermistor protection level
3D BD 5



563
Energization time carrying-over times
3F BF 5
  
564
Operating time carrying-over times
40 C0 5
 
570
Multiple rating setting
46 C6 5

 
571
Holding time at a start
47 C7 5
 
573
4mA input check selection
49 C9 5
  
575
Output interruption detection time
4B CB 5
 
576
Output interruption detection level
4C CC 5
  
577
Output interruption cancel level
4D CD 5
 
578
Auxiliary motor operation selection
4E CE 5
  
579
Motor connection function selection
4F CF 5
 
580
MC switching interlock time
50 D0 5
  
581
Start waiting time
51 D1 5
 
582
Auxiliary motor connection-time
deceleration time
52 D2 5
  
583
Auxiliary motor disconnection-time
acceleration time
53 D3 5
 
584
Auxiliary motor 1 starting frequency
54 D4 5
  
585
Auxiliary motor 2 starting frequency
55 D5 5
 
586
Auxiliary motor 3 starting frequency
56 D6 5
  
587
Auxiliary motor 1 stopping frequency
57 D7 5
 
588
Auxiliary motor 2 stopping frequency
58 D8 5
  
589
Auxiliary motor 3 stopping frequency
59 D9 5
 
590
Auxiliary motor start detection time
5A DA 5
  
591
Auxiliary motor stop detection time
5B DB 5
 
592
Traverse function selection
5C DC 5
  
593
Maximum amplitude amount
5D DD 5
 
594
Amplitude compensation amount during
deceleration
5E DE 5
  
595
Amplitude compensation amount during
acceleration
5F DF 5
 
596
Amplitude acceleration time
60 E0 5
  
597
Amplitude deceleration time
61 E1 5
 
611
Acceleration time at a restart
0B 8B 6
  
653
Speed smoothing control
35 B5 6
 
654
Speed smoothing cutoff frequency
36 B6 6
  
665
Regeneration avoidance frequency gain
41 C1 6
 
726
Auto Baudrate/Max Master
1A 9A 7
  
727
Max Info Frames
1B 9B 7
 
728
Device instance number (Upper 3 digit)
1C 9C 7
  
729
Device instance number (Lower 4 digit)
1D 9D 7
 
753
Second PID action selection
35 B5 7
  
754
Second PID control automatic switchover
frequency
36 B6 7
 
755
Second PID action set point
37 B7 7
  
756
Second PID proportional band
38 B8 7
 
757
Second PID integral time
39 B9 7
  
758
Second PID differential time
3A BA 7
 
759
PID unit selection
3B BB 7
  
760
Pre-charge fault selection
3C BC 7
 
761
Pre-charge ending level
3D BD 7
  
762
Pre-charge ending time
3E BE 7
 
763
Pre-charge upper detection level
3F BF 7
  
Parameter Name
Instruction Code *1
Parameter
Copy
*2
Parameter
Clear
*2
All Parameter
Clear
*2
Read Write Extended
