Mitsubishi M80 series

M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
91
IB-1501269-J
(a) Outline of digital signal input circuit
Both 24V common and 0V common connections are allowed in the digital signal input circuit.
Follow the wiring diagram below for each type.
Input circuit
[FCU8-DX731 / FCU8-DX750 / FCU8-DX760 / FCU8-DX761]
[FCU8-DX834]
X200
X21F
0V
FG
3.3kΩ
DICOM
0V
FG
3.3kΩ
DICOM
CG31/CG35CG31/CG35
X240
X25F
X200
X21F
X240
X25F
24VDC(+)
24V common
Control
circuit
Stabilized
power supply
External contact
24VDC(+)
0V common
Stabilized
power supply
External contact
Control
circuit
X200
X23F
0V
FG
5kΩ
DICOM
X200
X23F
0V
FG
5kΩ
DICOM
24VDC(+)
24V common
Control
circuit
Stabilized
power supply
External contact
24VDC(+)
0V common
Stabilized
power supply
External contact
Control
circuit
CG31/CG33CG31/CG33
