M800S/M80/E80 Series Connection and Setup Manual
8 Connection of Keyboard Unit
260
IB-1501269-J
The method for connecting to each unit and device from the keyboard unit is briefly explained in this chapter.
8.1 Keyboard Unit Connection System Drawing
8.2 Connecting with Operation Panel I/O Unit
Connect the operation panel I/O unit to connector of the keyboard unit.
NCKB
G402
Operation panel I/O unit
cable
Keyboard unit
NCKB
G402
Operation panel I/O unit Keyboard unit
(Rear view)
cable
