M800S/M80/E80 Series Connection and Setup Manual
1 System Basic Configuration
2
IB-1501269-J
1.1 System Basic Configuration Drawing
(Note) For the drive unit configuration, refer to the Instruction Manual of the drive unit you use.
(Control unit is added onto
back of display unit.)
Motor group
Servo/Spindle
drive unit
Manual pulse generator
Manual pulse penerator
Remote I/O unit
Remote I/O unit
Display unit
Operation panel I/O unit
Control unit
(Operation panel I/O unit is added
onto back of keyboard unit.)
Keyboard unit
Synchronous
feed encoder

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
