M800S/M80/E80 Series Connection and Setup Manual
29 Setting the Deceleration Check
537
IB-1501269-J
29.5 Relation with Other Functions
(1) Tool compensation
When the tool compensation is performed, the deceleration check will be operated on the block after compensation.
(2) Control axis synchronization (G125), control axis superimposition (G126), arbitrary axis exchange (G140), arbitrary
axis superimposition (G156)
When control axis synchronization (G125), control axis superimposition (G126), arbitrary axis exchange (G140) or
arbitrary axis superimposition (G156) is performed in the other part system, the succeeding block start timing may
be delayed in the cutting block to which the axis related to these functions belongs.
(3) Automatic error detect
The deceleration check is invalid in the block with the automatic error detect ON, the block complete condition
follows the automatic error detect.
(4) High-speed machining mode
When the axis movement reverses to the opposite direction in G01 to G01 successive block during the high-speed
machining mode, the commanded deceleration will not be performed even if G1Ipfg has been set to "1". When the
axis movement reverses to the opposite direction in G01 to G00 successive block, it follows the setting of G0Ipfg.
(5) High-speed simple program check
The deceleration check is performed during the high-speed operation in the high-speed simple program check also.
The deceleration check time is reduced according to the time reduction coefficient during the high-speed simple
program check operation.
(6) Deceleration check in polar coordinate interpolation / milling interpolation / cylindrical start / cancel command
- The deceleration check in polar coordinate interpolation / milling interpolation / cylindrical start / cancel
command are as follows.
Parameter: #1223 aux07 BIT1 Deceleration check method
0 Command deceleration check
1 In-position check
