Mitsubishi M80 series User Manual

M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
18
IB-1501269-J
3.7 Keyboard Unit [M800S]
3.8 Keyboard Unit [M80]
3.9 Keyboard Unit [E80]
Classification Type Components Remarks
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB041
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for L system, XZF)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB046
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for M system/L system, XYZ)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB047
Escutcheon, key switch
G402 cable
Screw cap set
Full keyboard (for M system/L system) (in tandem)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB048
Escutcheon, key switch
G402 cable
Screw cap set
ABC layout (for M system/L system)
Keyboard for 15-type display unit
Clear keys
FCU8-KB083
Escutcheon, key switch
G402 cable
Screw cap set
Full keyboard (for M system/L system) (in tandem)
Classification Type Components Remarks
Keyboard for 8.4-type display unit
Clear keys
FCU8-KB026
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for M system/L system, XYZ)
Keyboard for 8.4-type display unit
Clear keys
FCU8-KB028
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for L system, XZF)
Keyboard for 8.4-type display unit
Clear keys
FCU8-KB029
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for M system/L system) (in tandem)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB041
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for L system, XZF)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB046
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for M system/L system, XYZ)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB047
Escutcheon, key switch
G402 cable
Screw cap set
Full keyboard (for M system/L system) (in tandem)
Keyboard for 10.4-type display unit
Clear keys
FCU8-KB048
Escutcheon, key switch
G402 cable
Screw cap set
ABC layout (for M system/L system)
Keyboard for 15-type display unit
Clear keys
FCU8-KB083
Escutcheon, key switch
G402 cable
Screw cap set
Full keyboard (for M system/L system) (in tandem)
Classification Type Components Remarks
Keyboard for 8.4-type display unit
Sheet keys
FCU8-KB024
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for M system/L system, XYZ)
Keyboard for 8.4-type display unit
Sheet keys
FCU8-KB025
Escutcheon, key switch
G402 cable
Screw cap set
ONG layout (for L system, XZF)

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
