M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
170
IB-1501269-J
4.15 Manual Pulse Generator
4.15.1 5V Manual Pulse Generator (UFO-01-2Z9)
100 pulse/rev
[Outline dimension]
[Panel cut dimension]
Produced by NIDEC NEMICON CORPORATION


 3-M4

[mm]
0
10
20
30
40
50
60
70
80
90
0V A B
80.5
60
61626
R43
56
58 77
8.89 7.6 M3
x
6
5V
Gasket
Above size only
72 at equal pitch
Panel cut diameter
stud
Index

[mm]
72
62
at equal pitch

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
