M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
25
IB-1501269-J
3.25 List of Cables
[Cable relating to NC]
(Note 1) "x" in type columns indicate cable length (unit: m).
(Note 2) Lengths indicated with an asterisk (*) in the max. cable length column indicate the maximum cable length
when connecting via other unit.
Type Application Available cable length (m)
Max. cable
length
FCUA-R050-xM Synchronous encoder - control unit (straight, with connector) 5 30m
FCUA-R054-xM Synchronous encoder - control unit (right angle, with connector) 3, 5, 10, 15, 20 30m
G071 LxM 24VDC relay cable for MITSUBISHI CNC machine operation panel 0.12, 0.5, 1 1m
G123 Cable for emergency stop release - -
G430 LxM Cable for connection to handy terminal 3, 5, 10 10m
G460 LxM
Cable for MITSUBISHI CNC machine operation panel
(Cable between main panel and sub panel)
0.5 0.5m
J010 LxM Operation panel I/O interface cable 0.5, 1 1m
J012 LxM Operation panel I/O interface cable (for FCU8-DX834) 0.5, 1 1m
J020 LxM Manual pulse generator cable (12V): 1ch 1, 2, 3, 5, 7, 10, 15, 20, 30 50m
J021 LxM Manual pulse generator cable (12V): 2ch 1, 2, 3, 5, 7, 10, 15, 20, 30 50m
J022 LxM Manual pulse generator cable (12V): 3ch 1, 2, 3, 5, 7, 10, 15, 20, 30 50m
J023 LxM Manual pulse generator cable (5V): 1ch 1, 2, 3, 5, 7, 10, 15, 20 20m
J024 LxM Manual pulse generator cable (5V): 2ch 1, 2, 3, 5, 7, 10, 15, 20 20m
J025 LxM Manual pulse generator cable (5V): 3ch 1, 2, 3, 5, 7, 10, 15, 20 20m
J026 LxM
Manual pulse generator cable (5V): 1ch
(for connection to control unit)
1, 2, 3, 5, 7, 10, 15, 20 20m (*)
J027 LxM
Manual pulse generator cable (5V): 2ch
(for connection to control unit)
1, 2, 3, 5, 7, 10, 15, 20 20m (*)
J030 LxM RS-232C I/F cable: 1ch 1, 2, 3, 5, 7, 10 15m (*)
J031 LxM RS-232C I/F cable: 2ch 1, 2, 3, 5, 7, 10 15m (*)
J070 LxM 24VDC power cable 1, 2, 3, 5, 7, 10, 15 15m
J071 LxM 24VDC power cable (for long distance) 20 20m
J100 LxM SKIP input cable 1, 2, 3, 5, 7, 10, 15, 20 20m
J120 LxM Emergency stop cable 1, 2, 3, 5, 7, 10, 15, 20, 30 30m
J121 LxM Emergency stop cable for MITSUBISHI CNC machine operation panel 1, 2, 3, 5, 7, 10, 15, 20, 30 30m
J210 LxM Remote I/O 2.0 communication cable 0.3, 1, 2, 3, 5, 7, 10, 15, 20, 30 50m (*)
J221 LxM Analog input/output cable (for remote I/O unit) 2, 3, 7 30m
J224 LxM Analog input/output cable (for operation panel I/O unit) 1, 2, 3, 5, 7, 10, 15, 20 30m
J225 LxM Analog output cable (for operation panel I/O unit) 1, 2, 3, 5, 7, 10, 15, 20 30m
J303 LxM LAN straight cable 1, 2, 3, 5, 7, 10, 15, 20, 30 50m
J350 LxM DI/DO cable (connectors at both ends) 1, 2, 3, 5 50m
J351 LxM DI/DO cable (connector at one end) 3 50m
J460 LxM DI/DO cable (connectors at both ends) 1, 2, 3, 5 50m
J461 LxM DI/DO cable (connector at one end) 3 50m
R2-TM Terminator for remote I/O interface - -

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
