M800S/M80/E80 Series Connection and Setup Manual
7 Connection of Control Unit
235
IB-1501269-J
7.6 Connecting with Drive Unit
Connect the optical communication cables from the NC to the each drive unit so that they run in a straight line from the
NC to the drive unit that is a final axis. Note that the number of connected axes is limited by the NC.
(Note) Refer to "Precautions for Using Optical Communication Cable" when handling and wiring optical
communication cable.
Cable application table
Cable
Panel internal wiring Panel external wiring
Under 10m 10 to 30m 10m or less 10 to 30m
J396
○
×× ×
J395
○
×
○
×
G380
○○ ○ ○

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
