M800S/M80/E80 Series Connection and Setup Manual
15 Cable
366
IB-1501269-J
15.3.5 CNV2E-D Cable
Max. cable length: 30m
Application: MDS-B-SD unit cable
<Cable connection diagram>
15.3.6 CNV2E-HP Cable
Max. cable length: 30m
Application: MDS-B-HR unit cable
<Cable connection diagram>

1
2
9
10
3
4
5
6
7
8
PE
20
11
10
1
9
7
17
6
16
PE
P5(+5V)
LG
RQ
RQ*
SD
SD*
P5(+5V)
LG
P5(+5V)
LG
BAT
RQ
RQ*
SD
SD*
0.5mm
2
0.5mm
2
0.2mm
2
0.2mm
2
Drive unit side connector
(3M)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(MOLEX)
Connector set: 54599-1019
MDS-B-SD unit side connector
Connector: 10120-3000VE
Shell kit: 10320-52F0-008
Case
grounding
Case
grounding
(3M)
1
2
10
3
4
5
6
7
8
P
E
5
7
6
8
1
2
3
4
PE
P5(+5V)
LG
RQ
RQ*
SD
SD*
P5(+5V)
LG
P5(+5V)
LG
RQ
RQ*
SD
SD*
0.5mm
2
0.5mm
2
0.2mm
2
0.2mm
2
Drive unit side connector
(3M)
Receptacle: 36210-0100PL
Shell kit: 36310-3200-008
(MOLEX)
Connector set: 54599-1019
MDS-B-HR unit side connector
Plug: RM15WTPZ-8S(71)
Clamp: JR13WCCA-10(72)
Case
grounding
Case
grounding
(Hirose Electric)
