M800S/M80/E80 Series Connection and Setup Manual
15 Cable
370
IB-1501269-J
15.3.11 MR-BKS1CBL-A1-H / MR-BKS1CBL-A2-H Cable
Max. cable length: 10m
Application: <200V Series> Brake cable for HG96
MR-BKS1CBL-A1-H (load side angle)
MR-BKS1CBL-A2-H (reverse load side angle)
<Cable connection diagram>
15.3.12 MR-BT6V2CBL Cable
Max. cable length: 1m
Application: Battery cable (MDS-EJ/EJH)
(drive unit - drive unit)
AWG 20
AWG 20
B1
B2
Servo motor brake connector
(Japan Aviation Electronics)
Connector: JN4FT02SJ1-R
Bushing and Ground nut
Contact: ST-TMH-S-C1B-100(A534G)
Crimp tool: CT160-3TMH5B
Hood, Socket insulator,
BT
1
LG
2
BT
1
LG
2
BT
1
LG
2
0.12mm
2
0.12mm
2
Drive unit side connector
(J.S.T)
Connector : PAP-02V-O
Contact: SPHD-001G-P0.5
Drive unit side connector
(J.S.T)
Connector : PAP-02V-O
Contact: SPHD-001G-P0.5
Battery unit side connector
(J.S.T)
Connector : PALR-02VF
Contact: SPAL-001T-P0.5
