M800S/M80/E80 Series Connection and Setup Manual
9 Connection of Operation Panel I/O Unit
263
IB-1501269-J
9.2 Connecting with Power Supply
Connect 24VDC power supply (general-purpose stabilized power supply) to the operation panel I/O unit.
<Related items>
Cable drawing: "Cable: J070/J071 Cable"
Connector pin assignment: "General Specifications: Operation Panel I/O Unit" (DCIN connector)
0V
+24V
DCIN
DCIN
Y
FG
J070/J071
Operation panel
I/O unit
24VDC stabilized
power supply
