M800S/M80/E80 Series Connection and Setup Manual
17 Setting the Hardware
408
IB-1501269-J
17.6.5 Thermistor Input Interface
(1) By connecting the remote I/O unit with thermistor, up to 12 points of thermistor input are available.
For details on the unit which has thermistor input function, refer to "General Specifications: Remote I/O Unit".
(2) Up to 12 points of thermistor are detected in the ascending order of the channel No. and station No. of the remote I/
O unit. The file registers which output the temperature information are assigned to the inputs (thermistor input n
(TIn)), but are not assigned to the 13th or later thermistor input. The relationship between thermistor inputs and file
registers is as follows:
[PLC input signal]
Through the interface you can read the temperature sensed by a thermistor connected to the designated connector
of thermistor input-equipped remote I/O unit.
Channel File register Data update cycle
TI0 ZR13028
The thermistor voltage acquired with the thermistor input-equipped
remote I/O unit is input after converted to a temperature value per
PLC medium-speed cycle.
One station of remote I/O has 4 thermistor inputs, thus 4 PLC
medium-speed cycles are required for the inputs of one station.
TI1 ZR13029
TI2 ZR13030
TI3 ZR13031
TI4 ZR13032
TI5 ZR13033
TI6 ZR13034
TI7 ZR13035
TI8 ZR13036
TI9 ZR13037
TI10 ZR13038
TI11 ZR13039
To Next Page
