M800S/M80/E80 Series Connection and Setup Manual
7 Connection of Control Unit
245
IB-1501269-J
7.8 Connecting with RS-232C Device
(1) Connect the RS-232C device to SIO connector of the control unit.
<Related items>
Cable drawing: "Cable: J030/J031 Cable"
Connector pin assignment: "General Specifications: Control Unit" (SIO connector)
1ch 2ch
J031
SIO
J031 cable
J030 cable
Cable name
RS-232C device
Control unit
