M800S/M80/E80 Series Connection and Setup Manual
29 Setting the Deceleration Check
536
IB-1501269-J
(3) Designation of in-position check width
(a) Servo parameter
(b) Axis specification parameter
# Item Details Setting range
2224
SV024
INP
In-position
detection width
Set the in-position detection width.
Set the accuracy required for the machine.
The lower the setting is, the higher the positioning
accuracy gets; however, the cycle time (setting time)
becomes longer.
The standard setting value is "50".
0 to 32767 (μm)
13024
SP024
INP
In-position width
Set the in-position detection width.
Set the positioning accuracy required to the machine.
Lower setting value increases the positioning accuracy,
but prolongs the cycle time (settling time).
The standard setting is "875".
0 to 32767
(1deg/1000)
# Item Details Setting range
2077 G0inps
G0
in-position width
Set the in-position width for G0.
Between SV024 and this parameter, the parameter with
a larger value will be applied.
When "0" is set, this parameter will be invalid: only
SV024 will be available.
0.000 to 99.999 (mm)
2078 G1inps
G1
in-position width
Set the in-position width for G1.
Between SV024 and this parameter, the parameter with
a larger value will be applied.
When "0" is set, this parameter will be invalid: only
SV024 will be available.
0.000 to 99.999 (mm)
