M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
113
IB-1501269-J
[Outline dimension : FCU8-DX231]
[Outline dimension : FCU8-DX202]
(Space required above the unit)(Space required below the unit)
(Space
required for
wiring)
40
168 2.5
45 115
4
[mm]
30 30
40
168 2.5
80 115
4
[mm]
(Space required for
wiring)
