M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
188
IB-1501269-J
Terminal connections
25
13
9
SW2_C11
10
SW2_C12
21
SW2_C21
22
SW2_C22
11
SW1_NC11
12
SW1_NC12
23
SW1_NC21
24
SW1_NC22
18
SW6_NO1
19
SW6_C1
+5V
0V
24VDC(+)
24VDC(-)
Handy terminal side
Insulation type
DC-DC
converter
Enable switch
Emergency stop switch
Switchover switch
24VDC input
