M800S/M80/E80 Series Connection and Setup Manual
5 Installation
195
IB-1501269-J
The following shows an example of calculation applied to heat radiation countermeasures for the operation panel when
15-type display unit is used. Because heat will accumulate in the upper portions of the unit, install an agitating fan as
required.
120
320
400
600
500
140
400
Display unit
(Agitating fan)
Keyboard unit
