Mitsubishi M80 series User Manual

M800S/M80/E80 Series Connection and Setup Manual
10 Connection of Remote I/O Unit
300
IB-1501269-J
[Machine input (wiring example 2) : FCU8-DX213 / FCU8-DX213-1]
FCU8-DX213/213-1
X09
X0A
X0B
X0C
X0D
X0E
X0F
X01
X02
X03
X04
X05
X06
X07
X08
CJ35
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
9
19
10
20
CJ36
X00
0V
FG
IO0VA
IO0VB
0V
FG
1
2
3
DCIN
+24V
0V
FG
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
COMB+
COMA+
IO24VA
IO24VB
24VDC(+)
24VDC(+)
Stabilized
power supply
Machine side
Stabilized
power supply

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
