M800S/M80/E80 Series Connection and Setup Manual
10 Connection of Remote I/O Unit
304
IB-1501269-J
[Safety machine output : FCU8-DX654 / FCU8-DX654-1]
1
2
3
4
5
6
7
8
SDO
11
12
13
14
15
16
17
18
SY00A
COMA-
COMB-
COMA-
COMB-
COMA-
COMB-
COMA-
COMB-
SY00B
SY01A
SY01B
SY02A
SY02B
SY03A
SY03B
9
19
10
20
0V
FG
IO24VA
IO24VB
IO0VA
IO0VB
0V
FG
FCU8-DX654/654-1
0V
FG
1
2
3
DCIN
+24V
0V
FG
Safety relay
Load
Safety relay
Load
Safety relay
Load
Safety relay
Load
24VDC(+)
Stabilized
power supply
Machine side
24VDC(+)
Stabilized
power supply
24VDC(+)
Stabilized
power supply
