M800S/M80/E80 Series Connection and Setup Manual
17 Setting the Hardware
394
IB-1501269-J
Unit type Machine control signals that can be handled Total
Number of
occupied
stations
FCU8-DX220
Digital input signal (DI) 32 points
1
Digital output signal (DO) 32 points
FCU8-DX230
Digital input signal (DI) 64 points
2
Digital output signal (DO) 48 points
FCU8-DX231
Digital input signal (DI) 64 points
2Digital output signal (DO) 48 points
Analog output (AO) 1 point
FCU8-DX202
Analog input signal (AI) 4 points
1
Analog output signal (AO) 1 point
FCU8-DX213 / DX213-1
Digital input signal (DI) 16 points
1
Digital output signal (DO) 8 points
FCU8-DX654 / DX654-1
Safety digital input signal (DI) 8 points
2
Safety digital output signal (DO) 4 points
FCU8-DX651
Digital input signal (DI) 32 points
3
Digital output signal (DO) 32 points
Safety digital input signal (DI) 8 points
Safety digital output signal (DO) 4 points
FCU8-DX408 Thermistor input (THERMISTOR) 12 points 3
FCU8-DX409 Multi-analog input (Multi AI) 4 points 4

Mitsubishi M80 series Specifications

General

Type	CNC Control Unit
Power Supply	24V DC
Interpolation	Linear, circular, helical
Fieldbus	CC-Link
Operating Temperature	0 to 45°C
Interface	USB, RS-232
Processor	RISC processor
Ethernet	Yes (100BASE-TX/10BASE-T)
