28 Setting the Handy Terminal
525
IB-1501269-J
(3) Select [Online] - [Communication setting] from the menu of "NC Designer HT" and confirm the communication
condition is as follows.
Port: Personal computer port
Transmission: 19200 [bps]
Data length: 8 [bit]
Stop bit: 2
Parity: None
(4) Select [Online] - [Download] from the menu of "NC Designer HT".
(5) The following dialog box is displayed. Select "Yes".
(6) If a password has been set to the downloaded customized data, the "Input password" dialog box will be displayed.
Input the password and select "OK".
