Mitsubishi MELSEC-Q QD77MS User Manual

4 - 17
Chapter 4 Installation, Wiring and Maintenance of the Produc
t
• Bundle fixing
Optical cord should be given loose slack to avoid from becoming smaller than
the minimum bend radius, and it should not be twisted. When laying cable, fix
and hold it in position with using cushioning such as sponge or rubber which
does not contain plasticizing material.
Base unit
QD77MS
Bundle material
Recommended product
NK clamp SP type (NIX, INC.)
Optical cord
Loose slack
Cable
Panel
