Section 1
Section 1 Product Specifications and Handling
Section 1 is configured for the following purposes (1) to (5).
(1) To understand the outline of positioning control, and the QD77MS specifications
and functions
(2) To carry out actual work such as installation and wiring
(3) To set parameters and data required for positioning control
(4) To create a sequence program required for positioning control
(5) To understand the memory configuration and data transmission process
When diverting any of the program examples introduced in this manual to the actual
system, fully verify that there are no problems in the controllability of the target system.
Read "Section 2" for details on each control.
Chapter 1 Product Outline ............................................................................................. 1- 1 to 1- 30
Chapter 2 System Configuration.................................................................................... 2- 1 to 2- 8
Chapter 3 Specifications and Functions........................................................................ 3- 1 to 3- 34
Chapter 4 Installation, Wiring and Maintenance of the Product ................................... 4- 1 to 4- 20
Chapter 5 Data Used for Positioning Control ................................................................ 5- 1 to 5-194
Chapter 6 Sequence Program Used for Positioning Control........................................ 6- 1 to 6- 76
Chapter 7 Memory Configuration and Data Process .................................................... 7- 1 to 7- 20
