9 - 87
Chapter 9 Major Positioning Control
9.2.15 4-axis speed control
In "4-axis speed control" ("
Da.2
Control system" = Forward run: speed 4, Reverse
run: speed 4), control is carried out in the 4-axis direction in which the positioning data
has been set by continuously outputting pulses for the speed set in "
Da.8
Command
speed" until the input of a stop command.
The two types of 4-axis speed control are "Forward run: speed 4" in which the control
starts in the forward run direction, and "Reverse run: speed 4" in which control starts in
the reverse run direction.
(Refer to Section 9.1.6 "Interpolation control" for the combination of the reference axis
with the interpolation axes.)
