Chapter 1 Product Outline
1.2 Flow of system operation
1.2.1 Flow of all processes
The positioning control processes, using the QD77MS, are shown below.
Servo
amplifiers, etc.
DesignPreparationOperationMaintenance
PLC CPU
QD77MS
GX Works2
1)
2)
Installation, wiring
Writing of program
4)
Creation of sequence
program for operation
3)
5)
6)
Connection confirmation
Test operation
Actual operation
Maintenance
Disposal
Monitor
9)
10)
11)
8)
7)
Monitoring and
debugging of
operation program
Monitoring and
debugging of setting
data with test function
Writing of setting data
Understand the functions and performance, and determine the
positioning operation method (system design)
Setting of parameters
and data for QD77MS
To Next Page
