9 - 125
Chapter 9 Major Positioning Control
9.2.20 NOP instruction
The NOP instruction is used for the nonexecutable control system.
Operation
The positioning data No. to which the NOP instruction is set transfers, without any
processing, to the operation for the next positioning data No.
Positioning data setting examples
[When "NOP instruction" is set in positioning data No.1 of axis 1]
Setting example
Setting item
QD77MS2
QD77MS4
QD77MS16
Setting details
Da.1
Operation pattern – Setting not required (Setting value is ignored.)
Da.2
Control system NOP instruction Set the NOP instruction
Da.3
Acceleration time No. –
Da.4
Deceleration time No. –
Da.5
A
xis to be interpolated
QD77MS2 QD77MS4
–
Da.6
Positioning address/
movement amount
–
Da.7
Arc address –
Da.8
Command speed –
Da.9
Dwell time –
Da.10
M code –
Da.20
A
xis to be interpolated
No.1
QD77MS16
–
Da.21
Axis to be interpolated
No.2
QD77MS16
–
Axis 1 Positioning data No. 1
Da.22
A
xis to be interpolated
No.3
QD77MS16
–
Setting not required (Setting value is ignored.)
(Note): Refer to Section 5.3 "List of positioning data" for information on the setting details.
Restrictions
An error "Control system setting error (error code: 524)" will occur if the "NOP
instruction" is set for the control system of the positioning data No. 600.
POINT
<Use example of NOP instruction>
If there is a possibility of speed switching or temporary stop (automatic deceleration) at a point
between two points during positioning, that data can be reserved with the NOP instruction to change
the data merely by the replacement of the identifier.
