Mitsubishi MELSEC-Q QD77MS - Buffer Memory Area Configuration

7 - 5
Chapter 7 Memory Configuration and Data Process
7.1.2 Buffer memory area configuration
The QD77MS buffer memory is configured of the following types of areas.
Buffer memory address
Buffer memory area configuration
QD77MS2/QD77MS4 QD77MS16
Writing
possibility
Basic parameter area 0+150n to 15+150n
Detailed parameter area 17+150n to 69+150n
OPR basic parameter area 70+150n to 78+150n
OPR detailed parameter area 79+150n to 91+150n
Expansion parameter area 100+150n to 149+150n
Parameter area
Mark detection setting parameter
area
54000+20k to 54019+20k
Possible
System monitor area
1200 to 1499
31300 to 31549
4000 to 4299
31300 to 31549
Axis monitor area 800+100n to 899+100n 2400+100n to 2499+100n
Monitor data area
Mark detection monitor data area 54960+80k to 55039+80k
Not possible
System control data area 1900 to 1999 5900 to 5999
Axis control data area 1500+100n to 1599+100n 4300+100n to 4399+100n
Expansion axis control data area 30100+10n to 30109+10n
Control data area
Mark detection control data area 54640+10k to 54649+10k
Positioning data area
(No.1 to 100)
2000+6000n to 2999+6000n 6000+1000n to 6999+1000n
Positioning data area
(No.101 to 600)
Positioning data area
3000+6000n to 7999+6000n Set with GX Works2
26000+1000n to 26049+1000n 22000+400n to 22049+400n
Block start data area
26050+1000n to 26099+1000n 22050+400n to 22099+400n
Block start data area
(No.7000)
Condition data area 26100+1000n to 26199+1000n 22100+400n to 22199+400n
26200+1000n to 26249+1000n 22200+400n to 22249+400n
Block start data area
26250+1000n to 26299+1000n 22250+400n to 22299+400n
Block start data area
(No.7001)
Condition data area 26300+1000n to 26399+1000n 22300+400n to 22399+400n
26400+1000n to 26449+1000n
Block start data area
26450+1000n to 26499+1000n
Block start data area
(No.7002)
Condition data area 26500+1000n to 26599+1000n
26600+1000n to 26649+1000n
Block start data area
26650+1000n to 26699+1000n
Block start data area
(No.7003)
Condition data area 26700+1000n to 26799+1000n
26800+1000n to 26849+1000n
Block start data area
26850+1000n to 26899+1000n
Block start data area
(No.7004)
Condition data area 26900+1000n to 26999+1000n
Set with GX Works2
PLC CPU memo area PLC CPU memo area 30000 to 30099
Possible
