14 - 7
Chapter 14 Common Functions
14.4 External signal selection function
The "external signal selection function" is used to select the external input signal of
QD77MS, external input signal of servo amplifier (PIN No. CN3-2, CN3-12, CN3-19) or
external input signal via CPU (buffer memory of QD77MS) when using the upper/lower
limit signal and near-point dog signal.
When the external input signal via CPU (the buffer memory of QD77MS) is used, the
external input signal status of QD77MS can be operated by connecting the limit switch
to input module and by operating the buffer memory of sequence program. When the
external input signal via CPU (the buffer memory of QD77MS) is used, operation is
affected by the PLC scan time.
The details shown below explain about the "External signal selection function".
[1] Parameter setting details
[2] Precautions during parameter setting
[3] Control details
[1] Parameter setting details
The use the "External signal selection function", set the parameters shown in the
following table.
Buffer memory address
Setting item Setting value Setting details
QD77MS2
QD77MS4
QD77MS16
Pr.80
External
input signal
selection
QD77MS2 : 0
QD77MS4 : 0
QD77MS16: 1
Set the external signal selection.
0: External input signal of QD77MS
QD77MS2 QD77MS4
1: External input signal of servo amplifier
2: Buffer memory of QD77MS
3: External input signal 1 of QD77MS
QD77MS16
4: External input signal 2 of QD77MS
QD77MS16
5: External input signal 3 of QD77MS
QD77MS16
6: External input signal 4 of QD77MS
QD77MS16
32+150n
n: Axis No.-1
To Next Page
