10 - 13
Chapter 10 High-Level Positioning Control
10.3.6 Repeated start (FOR loop)
In a "repeated start (FOR loop)", the data between the " block start data" in which "4:
FOR loop" is set in "
Da.13
Special start instruction" and the "block start data" in which
"6: NEXT start" is set in "
Da.13
Special start instruction " is repeatedly executed for
the number of times set in "
Da.14
Parameter". An endless loop will result if the
number of repetitions is set to "0".
(The number of repetitions is set in "
Da.14
Parameter" of the " block start data" in
which "4: FOR loop" is set in "
Da.13
Special start instruction".)
Section [2] shows a control example where the " block start data" and "positioning
data" are set as shown in section [1].
[1] Setting examples
(1) Block start data setting example
Axis 1 block
start data
Da.11
Shape
Da.12
Start data No.
Da.13
Special start
instruction
Da.14
Parameter
1st point 1: Continue 1 4: FOR loop 2
2nd point 1: Continue 10 0: Block start –
3rd point 0: End 50 6: NEXT start –
•
•
(Note): The "condition data Nos." have been set in "
Da.14
Parameter".
(2) Positioning data setting example
Axis 1 positioning
data No.
Da.1
Operation pattern
1 01: Continuous positioning control
2 01: Continuous positioning control
3 00: Positioning complete
•
10 11: Continuous path control
11 00: Positioning complete
•
50 01: Continuous positioning control
51 00: Positioning complete
•
[2] Control examples
The following shows the control executed when the " block start data" of the 1st
point of axis 1 is set as shown in section [1] and started.
<1> Execute the axis 1 "positioning data No.1, 2, 3, 10, 11, 50, and 51".
<2> Return to the axis 1 "1st point block start data". Again execute the axis 1
"positioning data No.1, 2, 3, 10, 11, 50 and 51", and then stop the control.
(Repeat for the number of times (2 times) set in
Da.14
.)
