9 - 44
Chapter 9 Major Positioning Control
9.2.5 4-axis linear interpolation control
In "4-axis linear interpolation control" ("
Da.2
Control system" = ABS linear 4, INC
linear 4), four motors are used to carry out position control in a linear path while
carrying out interpolation for the axis directions set in each axis.
(Refer to Section 9.1.6 "Interpolation control" for details on interpolation control.)
[1] 4-axis linear interpolation control (ABS linear 4)
In the absolute system 4-axis linear interpolation control, the designated 4 axes
are used. Linear interpolation positioning is carried out from the current stop
position (start point address) to the address (end point address) set in the
"
Da.6
Positioning address/movement amount".
Restrictions
An error will occur and the positioning will not start in the following cases. The
machine will immediately stop if the error is detected during a positioning control.
•
When the movement amount for each axis exceeds "1073741824 (=2
30
)"
An "outside linear movement amount range error (error code: 504)" will occur at
the positioning start.
(The maximum movement amount that can be set in "
Da.6
Positioning
address/movement amount" is "1073741824 (=2
30
)".)
