Chapter 7 Memory Configuration and Data Process
Buffer memory address
Buffer memory area configuration
QD77MS2/QD77MS4 QD77MS16
Writing
possibility
Servo series
30100+200n 28400+100n
PA01 to PA18
30101+200n to 30118+200n 28401+100n to 28418+100n
PA19
30932+50n Set with GX Works2
PA group
PA20 to PA32
64400+250n to 64412+250n 64400+70n to 64412+70n
30119+200n to 30163+200n 28419+100n to 28463+100n
PB group
64413+250n to 64431+250n 64413+70n to 64431+70n
30164+200n to 30195+200n 28464+100n to 28495+100n
PC group
64432+250n to 64463+250n 64432+70n to 64463+70n
30196+200n to 30227+200n
PD group
64464+250n to 64479+250n
30228+200n to 30267+200n
PE group
64480+250n to 64503+250n
PS group 30268+200n to 30299+200n
30900+50n to 30915+50n
PF group
64504+250n to 64535+250n
30916+50n to 30931+50n
Po group
64536+250n to 64551+250n
Servo parameter area
PL group 64552+250n to 64599+250n
Set with GX Works2
Possible
Servo input axis parameter 32800+10n to 32805+10n Possible
Servo input axis monitor data 33120+10n to 33127+10n Not possible
Synchronous encoder axis
parameter
34720+20j to 34735+20j Possible
Synchronous encoder axis control
data
35040+10j to 35047+10j Possible
Synchronous encoder axis
monitor data
35200+20j to 35212+20j Not possible
Synchronous control system
control data
36320, 36322 Possible
Synchronous parameter 36400+200n to 36513+200n Possible
Synchronous control monitor data 42800+40n to 42835+40n Not possible
Control data for synchronous
control
44080+20n to 44090+20n Possible
Cam operation control data 45000 to 53791 Possible
Synchronous control
area
Cam operation monitor data 53800 to 53801 Not possible
n: Axis No.-1
k: Mark detection setting No.-1
j: Synchronous encoder axis No.-1
: Use of address Nos. skipped above is prohibited. If used, the system may not operate correctly.
