5 - 54
Chapter 5 Data Used for Positioning Control
Pr.45
OP address
Set the address used as the reference point for positioning control (ABS system).
(When the machine OPR is completed, the stop position address is changed to the
address set in "
Pr.45
OP address". At the same time, the "
Pr.45
OP address"
is stored in "
Md.20
Current feed value" and "
Md.21
Machine feed value".)
Pr.1
setting value
Value set with GX Works2
(unit)
Value set with sequence program
(unit)
0 : mm
-214748364.8 to 214748364.7 (
μ
m)
-2147483648 to 2147483647 (
×
10
-1
μ
m)
1 : inch -21474.83648 to 21474.83647 (inch)
-2147483648 to 2147483647 (
×
10
-5
inch)
2 : degree 0 to 359.99999 (degree)
0 to 35999999 (
×
10
-5
degree)
3 : PLS -2147483648 to 2147483647 (PLS) -2147483648 to 2147483647 (PLS)
Pr.46
OPR speed
Set the speed for OPR.
Note) Set the "OPR speed" to less than "
Pr.8
Speed limit value". If the "speed
limit value" is exceeded, the error "outside speed limit value range" (error
code: 910) will occur, and OPR will not be executed.
The "OPR speed" should be equal to or faster than the "
Pr.7
Bias speed
at start" and "
Pr.47
Creep speed".
Pr.1
setting value
Value set with GX Works2
(unit)
Value set with sequence program
(unit)
0 : mm 0.01 to 20000000.00 (mm/min)
1 to 2000000000 (
×
10
-2
mm/min)
1 : inch 0.001 to 2000000.000 (inch/min)
1 to 2000000000 (
×
10
-3
inch/min)
2 : degree
0.001 to 2000000.000 (degree/min)`
1
1 to 2000000000 (
×
10
-3
degree/min)
2
3 : PLS 1 to 1000000000 (PLS/s) 1 to 1000000000 (PLS/s)
1
: The OPR speed setting range is 0.001 to 2000000.000[degree/min], but it will be decupled and
become 0.01 to 20000000.00[degree/min] by setting "
Pr.83
Speed control 10 x multiplier
setting for degree axis" to valid.
2
: The OPR speed setting range is 1 to 2000000000(
×
10
-3
degree/min), but it will be decupled and
become 1 to 2000000000 (
×
10
-2
degree/min) by setting "
Pr.83
Speed control 10 x multiplier
setting for degree axis" to valid.
