5 - 78
Chapter 5 Data Used for Positioning Control
(g) Other setting parameters
Buffer memory address Buffer memory address
Servo amplifier
Parameter No.
QD77MS2
QD77MS4
QD77MS16
Servo amplifier
Parameter No.
QD77MS2
QD77MS4
QD77MS16
PF01 30900+50n PF09 30908+50n
PF02 30901+50n PF10 30909+50n
PF03 30902+50n PF11 30910+50n
PF04 30903+50n PF12 30911+50n
PF05 30904+50n PF13 30912+50n
PF06 30905+50n PF14 30913+50n
PF07 30906+50n PF15 30914+50n
PF08 30907+50n
Set with
GX Works2
PF16 30915+50n
Set with
GX Works2
n: Axis No.-1
(h) Option unit parameters
Buffer memory address Buffer memory address
Servo amplifier
Parameter No.
QD77MS2
QD77MS4
QD77MS16
Servo amplifier
Parameter No.
QD77MS2
QD77MS4
QD77MS16
Po01 30916+50n Po09 30924+50n
Po02 30917+50n Po10 30925+50n
Po03 30918+50n Po11 30926+50n
Po04 30919+50n Po12 30927+50n
Po05 30920+50n Po13 30928+50n
Po06 30921+50n Po14 30929+50n
Po07 30922+50n Po15 30930+50n
Po08 30923+50n
Set with
GX Works2
Po16 30931+50n
Set with
GX Works2
n: Axis No.-1
