5 - 93
Chapter 5 Data Used for Positioning Control
Da.10
M code (or condition data No./Number of LOOP to LEND repetitions)
Set an "M code", a "condition data No.", or the "Number of LOOP to LEND
repetitions" depending on how the "
Da.2
Control system" is set.
1
If a method other than "JUMP instruction" and "LOOP" is selected as the
"
Da.2
Control system"
............... Set an "M code".
If no "M code" needs to be output, set "0" (default value).
If "JUMP instruction" or "LOOP" is selected as the "
Da.2
Control system"
............... Set the "condition data No." for JUMP.
0 : Unconditional JUMP to the positioning data specified
by
Da.9
.
1 to 10 : JUMP performed according to the condition data No.
specified (a number between 1 and 10).
Make sure that you specify the number of LOOP to LEND repetitions
by a number other than "0". The "Control system LOOP setting error"
will occur if you specify "0". (error code: 545)
1: The condition data specifies the condition for the JUMP instruction to be
executed.
(A JUMP will take place when the condition is satisfied.)
Da.2
setting value
Setting item Value set with GX Works2
Value set with sequence
program
JUMP instruction: 82H Condition data No. 0 to 10 0 to 10
Other than JUMP instruction M code 0 to 65535 0 to 65535
LOOP: 83H Repetition count 1 to 65535 1 to 65535
To Next Page
