5 - 128
Chapter 5 Data Used for Positioning Control
Storage item Storage details
Md.24
Axis warning No.
Whenever an axis warning is reported, a related warning code is stored.
•
This area stores the latest warning code always. (Whenever an axis warning is
reported, a new warning code replaces the stored warning code.)
•
When the "
Cd.5
Axis error reset" (axis control data) is set to ON, the axis
warning No. is cleared to "0".
Refresh cycle: Immediate
Md.25
Valid M code
This area stores an M code that is currently active (i.e. set to the positioning data
relating to the current operation).
When the PLC READY signal [Y0] goes OFF, the value is set to "0".
Refresh cycle: Immediate
Md.26
Axis operation status
This area stores the axis operation status.
Refresh cycle: Immediate
Md.27
Current speed
The "
Da.8
Command speed" used by the positioning data currently being
executed is stored.
•
If "
Da.8
Command speed" is set to "-1", this area stores the command speed
set by the positioning data used one step earlier.
•
If "
Da.8
Command speed" is set to a value other than "-1", this area stores the
command speed set by the current positioning data.
•
When speed change function is executed, this area stores "
Cd.14
New speed
value". (For details of change speed function, refer to Section 13.5.1.)
Refresh cycle: Immediate
