5 - 190
Chapter 5 Data Used for Positioning Control
Setting item Setting details
Cd.152 Torque time constant at
continuous operation to
torque control mode
(Negative direction)
•
Set the time constant at regeneration during continuous operation to torque
control mode.
(Set the time for the torque to decrease from "
Pr.17 Torque limit setting value" to
"0".)
0 to 65535 (ms)
Fetch cycle: At control mode switching
Cd.153 Control mode auto-shift
selection
•
Set the switching condition when switching to continuous operation to torque
control mode.
0: No switching condition...... Switching is executed at switching request to
continuous operation to torque control mode.
1: Current feed value pass.... Switching is executed when "
Md.20 Current feed
value
" passes the address set in " Cd.154 Control
mode auto-shift parameter
" after switching request to
continuous operation to torque control mode.
2: Real current value pass.... Switching is executed when "
Md.101 Real current
value
" passes the address set in " Cd.154 Control
mode auto-shift parameter
" after switching request to
continuous operation to torque control mode.
Fetch cycle: At control mode switching
•
Set the condition value when setting the control mode switching condition.
•
The setting value differs depending on the value set in " Cd.153 Control mode auto-
shift selection
".
When "1" or "2" is set in "
Cd.153 Control mode auto-shift selection": Set the switching
address.
•
Set a value within the following range:
Pr.1 Unit setting
mm
(
×
10
-1
mm)
inch
(
×
10
-5
inch)
degree
(
×
10
-5
degree)
PLS
(PLS)
Setting range
-2147483648 to
2147483647
-2147483648 to
2147483647
0 to 35999999
-2147483648 to
2147483647
Cd.154 Control mode auto-shift
parameter
Fetch cycle: At control mode switching
